1. Instruction
1. Versatile: It is highly versatile and can bend a wide range of materials, including steel, aluminum, and copper.
2. Precise: The four rollers work together to ensure an even and precise bend, resulting in high-quality finished products.
3. High efficiency: This machine operates with high efficiency and can complete multiple bends in a single pass, leading to increased productivity.
4. Easy to use: These machines are designed with user-friendliness in mind and come with intuitive controls that make operation easy. Additionally, they require minimal setup time, making them ideal for small-batch production.
2. Technical Data:
|
Model |
Unit |
W12-20*3200 |
|
Max width |
mm |
3200 |
|
The length of working roller |
mm |
3250 |
|
Max thickness (central) |
mm |
T20*B3200*φmin800(σs≤245Mpa) |
|
max thickness (end) |
mm |
T16*B3200*φmin800(σs≤245MPa) |
|
Top roller diameter |
mm |
Φ400 |
|
Lower roller diameter |
mm |
Φ370 |
|
Side roller diameter |
mm |
Φ320 |
|
Rolling speed |
m/min |
About 4 |
|
Main motor power |
kW |
22 |
|
max working pressure of hydraulic system |
MPa |
19.5 |
3. Machine Details
|
Hydraulic System YUKEN from Japan |
CNC Control System |
|
High Quality Rollers |
Hydraulic drop end |
4. Final Products
The 4-roller plate bending machine can roll round, oval, and conical shapes. An optional cone device is available for the four-roller plate bending machine, allowing users to roll conical workpieces as needed.
Our Company Profile
Nantong Brisk CNC Co., Ltd is located at No. 52 Zhennan West Road, Libao Town, Nantong City, Jiangsu Province. Brisk CNC is a leading professional manufacturer of hydraulic press brakes, shearing machines, plate rolling machines, metal ironworkers, CNC presses, and other metalworking machinery.
Our company has a professional engineering team. We adopt the latest designs and advanced technology for press brakes, shearing machines, and CNC plate rolling bending machines. We also provide 24-hour online after-sales service.
FAQ
Q: Are you a trading company or a manufacturer?
A: We are a manufacturer of press brakes, shearing machines, plate rolling machines, ironworkers, and other metalworking machinery.
Q: What are your payment terms?
A: We accept T/T (Telegraphic Transfer), with a 30% deposit and the balance paid before shipment.
Q: What is your delivery time?
A: For stock machines: 7 working days after receiving the deposit.
For customized machines: 25 working days.
Q: What is your warranty?
A: Our warranty period is 12 months, with lifetime technical support for the machine.
Q: How can I place an order with your company?
A: Step 1:Confirm the quotation we send you.
Step 2: We will send you a proforma invoice, and you will transfer the deposit via bank transfer.
Step 3: We will start production once the payment is received.
Step 4:Once the machine is completed, we will arrange shipment.
