Our machine is widely used in sheet metal bending area, such as automobile, aircraft manufacturing, light industry, shipbuilding, container, elevator, railway vehicles and other industries.
Technical Parameters
Type | Nominal Force | Worktable Length | Poles Distance | Throat Depth | Stroke | Max Open | Power | Dimension |
(KN) | (mm) | (mm) | (mm) | (mm) | (mm) | (KW) | L*W*H(mm) | |
30T/1600 | 300 | 1600 | 1280 | 200 | 80 | 285 | 3 | 1600*1000*1600 |
35T/2000 | 350 | 2000 | 1480 | 200 | 80 | 285 | 4 | 2000*1100*1800 |
40T/2200 | 400 | 2200 | 1850 | 230 | 100 | 320 | 5.5 | 2200*1200*1910 |
40T/2500 | 400 | 2500 | 1850 | 230 | 100 | 320 | 5.5 | 2500*1200*1910 |
50T/2500 | 500 | 2500 | 1850 | 230 | 100 | 320 | 5.5 | 2500*1200*2000 |
63T/2500 | 630 | 2500 | 1900 | 250 | 120 | 320 | 5.5 | 2500*1300*2210 |
63T/3200 | 630 | 3200 | 2500 | 250 | 120 | 320 | 5.5 | 3200*1300*2210 |
80T/2500 | 800 | 2500 | 1900 | 300 | 120 | 320 | 7.5 | 2500*1400*2300 |
80T/3200 | 800 | 3200 | 2500 | 320 | 120 | 350 | 7.5 | 3200*1500*2300 |
80T/4000 | 800 | 4000 | 3000 | 320 | 120 | 350 | 7.5 | 4000*1500*2400 |
100T/2500 | 1000 | 2500 | 1900 | 320 | 160 | 320 | 7.5 | 2500*1600*2400 |
100T/3200 | 1000 | 3200 | 2500 | 320 | 160 | 370 | 7.5 | 3200*1600*2600 |
100T/4000 | 1000 | 4000 | 3000 | 320 | 160 | 370 | 7.5 | 4000*1600*2700 |
125T/3200 | 1250 | 3200 | 2500 | 320 | 160 | 370 | 7.5 | 3200*1600*2700 |
125T/4000 | 1250 | 4000 | 3000 | 320 | 160 | 370 | 7.5 | 4000*1600*2700 |
160T/3200 | 1600 | 3200 | 2500 | 320 | 200 | 460 | 11 | 3200*1700*2700 |
160T/4000 | 1600 | 4000 | 3000 | 320 | 200 | 460 | 11 | 4000*1700*2800 |
160T/5000 | 1600 | 5000 | 4000 | 320 | 200 | 460 | 11 | 5000*1900*3100 |
160T/6000 | 1600 | 6000 | 4940 | 320 | 200 | 460 | 11 | 6000*1900*3200 |
200T/3200 | 2000 | 3200 | 2500 | 320 | 200 | 460 | 11 | 3200*1950*2800 |
200T/4000 | 2000 | 4000 | 3000 | 320 | 200 | 460 | 11 | 4000*1950*2800 |
200T/5000 | 2000 | 5000 | 4000 | 320 | 200 | 460 | 11 | 5000*1950*3000 |
200T/6000 | 2000 | 6000 | 5000 | 320 | 200 | 460 | 11 | 6000*1950*3300 |
250T/3200 | 2500 | 3200 | 2500 | 400 | 250 | 460 | 18.5 | 3200*2000*3200 |
250T/4000 | 2500 | 4000 | 3000 | 400 | 250 | 590 | 18.5 | 4000*2000*3400 |
250T/5000 | 2500 | 5000 | 4000 | 400 | 250 | 590 | 18.5 | 5000*2000*3400 |
250T/6000 | 2500 | 6000 | 5000 | 400 | 250 | 590 | 18.5 | 6000*2000*3400 |
300T/5000 | 3000 | 5000 | 4000 | 400 | 250 | 570 | 22 | 5100*2600*4000 |
300T/6000 | 3000 | 6000 | 5000 | 400 | 250 | 570 | 22 | 6100*2600*4200 |
300T/7000 | 3000 | 7000 | 5620 | 400 | 250 | 570 | 22 | 7100*2600*4400 |
320T/7000 | 3200 | 7000 | 5620 | 400 | 250 | 570 | 22 | 7100*2600*4400 |
350T/6000 | 3500 | 6000 | 5100 | 450 | 250 | 570 | 30 | 6100*2600*4200 |
350T/7000 | 3500 | 7000 | 5620 | 450 | 250 | 570 | 30 | 7100*2500*4500 |
400T/4000 | 4000 | 4000 | 3100 | 350 | 300 | 620 | 30 | 4100*2700*3800 |
400T/6000 | 4000 | 6000 | 4820 | 400 | 320 | 620 | 30 | 6100*2800*4200 |
Machine Detail Display
main frame
machine in exhibition
fast clamp, double-v punch and die
Controller Options
CNC system adopts world well-known brands such as DELEM controller made in Netherlands, Cybelec controller made in Swiss and Esa made in Italy.
Estun 21 controller
● Monochrome LCD Box Panel.
● Integral factor programmable freely
● Automatic positioning control
● Spindle allowance offset
● Internal time relay
● Stock counter
● Backgauge position display, resolution in 0.05mm.
Delem-53T controller
● graphical touch screen.
● Standard Windows functions. User specific applications support.
● Emergency stop device.
● German HOERBIGER hydraulic circuit.
● Equipped with European optical scales.
● Precision ball screw lead, linear slide way and AC servo motor for X axis.
Delem-66T controller
● 2D graphical touch screen programming mode
●17" high resolution colour TFT
● Full Windows application suite
● Delem Modusys compatibility (module scalability and adaptivity)
● User specific application support within the control's multitasking environment
● Sensor bending & correction interface Profile-TL offline software
Cybelec Touch 8
● Simple page with clear display, and also with big touch buttons.
● Very simple single bend with EasyBend page.
● Complete programming can efficiently mass produce parts with multiple bends.
● Use PC or Notebook for comfortable wireless software update and data backup.
ESA 640 controller
● 2D graphical touch screen programming mode
● 10" high resolution colour TFT
● Supports analog bending
● Support for graphic or numerical arc bending
● Expand length calculation
Packing & Shipping
Machine be packed in wooden cases and fixed in wooden cases to ensure the intrgrity of the machines.
FAQ
a. Q: How long is the delivery time?
A: We can stock, and customzied hydraulic press brake machine delivery time is 25 working days.
b. Q: What is your warranty?
A: 18 months for whole machine, and support machine whole life time technical guide.
c. Q: What is your terms of payment?
A: Payment 30% T/T in advance, 70%balance before shippment.
d. Q: When I got order, What should I do?
A: There are video and English manual which ship with the machine together. If it still not helpful, we can camera online to guide you until the machine works good.
